3003 aluminum wire anti corrosion
Editor ：frank
Time ：2020-12-31 16:24
3003 aluminum alloy standard: GBT 3190-2008 chemical composition of wrought aluminum and aluminum alloy
Main features and application range: It is AL-Mn series alloy, which is the most widely used anti-rust aluminum. The strength of this alloy is not high (slightly higher than industrial pure aluminum) and cannot be strengthened by heat treatment, so cold working methods are used to improve Its mechanical properties: high plasticity in the annealed state, good plasticity during semi-cold work hardening, low plasticity during cold work hardening, good corrosion resistance, good weldability, and poor machinability. Uses are mainly used for low-load parts that require high plasticity and good weldability, working in liquid or gaseous media, such as fuel tanks, gasoline or lubricating oil pipes, various liquid containers and other low-load parts made by deep drawing: Wire is used to make rivets
3003 aluminum wire anti corrosion Chemical composition:
3003 aluminum alloy
Silicon Si: 0.60
Iron Fe: 0.70
Copper Cu: 0.05-0.20
Manganese Mn: 1.0-1.5
Zinc Zn: 0..10
Aluminum Al: margin
3003 aluminum wire anti corrosion mechanical performance:
Tensile strength σb (MPa)) 140-180
Conditional yield strength σ0.2 (MPa) )≥115
Sample size: all wall thickness
Note: Longitudinal mechanical properties of pipes at room temperature
Main features and application range: It is AL-Mn series alloy, which is the most widely used anti-rust aluminum. The strength of this alloy is not high (slightly higher than industrial pure aluminum) and cannot be strengthened by heat treatment, so cold working methods are used to improve Its mechanical properties: high plasticity in the annealed state, good plasticity during semi-cold work hardening, low plasticity during cold work hardening, good corrosion resistance, good weldability, and poor machinability. Uses are mainly used for low-load parts that require high plasticity and good weldability, working in liquid or gaseous media, such as fuel tanks, gasoline or lubricating oil pipes, various liquid containers and other low-load parts made by deep drawing: Wire is used to make rivets
3003 aluminum wire anti corrosion Chemical composition:
3003 aluminum alloy
Silicon Si: 0.60
Iron Fe: 0.70
Copper Cu: 0.05-0.20
Manganese Mn: 1.0-1.5
Zinc Zn: 0..10
Aluminum Al: margin
3003 aluminum wire anti corrosion mechanical performance:
Tensile strength σb (MPa)) 140-180
Conditional yield strength σ0.2 (MPa) )≥115
Sample size: all wall thickness
Note: Longitudinal mechanical properties of pipes at room temperature
